This Power Panel Component for Consumer Electronic Devices is an aluminum alloy part machined from a solid block using multi-axis CNC milling and serves as a core structural element of the equipment. The product structure is carved from a single aluminum plate via CNC milling, followed by an overall polishing process; the surface can be customized to include precisely positioned dowel holes, screw holes, and mounting points for inserts, tailored to the dimensions of the components to be installed.
Item No :
CNC-0002Order(MOQ) :
1Payment :
50% T/T in advance, Balance paid again when finishing production and before shipmentProduct Origin :
XiamenColor :
RAL、PANTONE、GSB05···Custom colorsShipping Port :
Xiamen Port,ChinaLead Time :
25-45daysWeight :
As per product's size and thickness and materials.Power Panel for Consumer Electronic Devices
Product Description: Elongated decorative covers for laptops, elongated power supply housings, industrial control panel casings, elongated router cavities, display bezels, elongated air conditioner trim strips, elongated panels for kitchen and bathroom appliances, elongated automotive ambient light housings, interior trim strips, elongated control panels for kitchen and bathroom fixtures, communication equipment housings, router cavities, and industrial control panel casings.
Model: OEM/ODM
Base Material: Thickness: 3–300mm. 6000-series aluminum alloys (6061, 6063, 6060, 6082) or 7000-series high-strength aluminum (7075-T6/T651, 7050, 7079); features high hardness, superior rigidity, and strong corrosion resistance, while meeting electromagnetic compatibility (EMC) standards.
Processing Workflow: Thick plate cutting → CNC rough milling to remove excess material → Semi-finishing of contours, holes, and mounting bases → Precision finishing of internal cavity walls → Mirror-finish polishing (achieving a mirror-like surface within the cavity) → Inspection and calibration of hole diameters and flatness.
The entire assembly—including cavities, mounting holes, and positioning structures—is machined via an integrated CNC process, ensuring high dimensional accuracy and uniform assembly clearances.
Precision: Plate external dimensions (length/width): ±0.01–±0.02 mm; Cavity dimensions (length/width/depth): ±0.005–±0.01 mm; Hole diameter tolerance: ±0.003–±0.005 mm
Surface Treatment: Customized based on corrosion and wear resistance requirements. Common processes include: mechanical rough/fine polishing, mirror polishing (high-gloss finish), brushed finish, natural/colored anodizing, chemical polishing, passivation (chromate or chromium-free), and powder coating (RAL, Pantone, GSB05-1426-2001 standards)
Unit Price: Quoted based on drawings
Packaging: Multi-layer anti-rust barrier + vacuum sealing + ample calcium chloride desiccant + thickened shock-absorbing foam + heavy-duty fumigated solid wood crate (or fumigation-free plywood crate/carton) + reinforced wooden corner protectors
Logistics: Sea freight, air freight, international express (DHL, FedEx, UPS, TNT), rail transport (primarily China-Europe freight trains), and road transport (short-haul cross-border trade with neighboring countries).
This Power Panel Component for Consumer Electronic Devices is an aluminum alloy part machined from a solid block using multi-axis CNC milling and serves as a core structural element of the equipment. The product structure is carved from a single aluminum plate via CNC milling, followed by an overall polishing process; the surface can be customized to include precisely positioned dowel holes, screw holes, and mounting points for inserts, tailored to the dimensions of the components to be installed.
View More
This PV Inverter Wall‑mount Bracket is an aluminum alloy part machined from a solid block via multi-axis CNC milling and serves as a core structural element of the equipment. The product structure is carved from a single aluminum plate using CNC milling, followed by an overall polishing process; positioning pin holes, screw holes, and mounting locations for inserts can be custom-configured based on the equipment's weight and dimensions.
View More
This Integrated Power Distribution Unit for Vehicle-Mounted Shelters features a standard rack-mount design and provides dual-channel, redundant, uninterruptible AC power to internal equipment—such as communication systems, operator consoles, displays, air conditioning, and lighting. It is engineered to withstand harsh vehicular operating conditions—including field mobility, vibration, temperature extremes, and hot-humid environments—and complies with electromagnetic compatibility (EMC) standards.
